WI4MPI

Source the setup env bash file:

$ source share/wi4mpi/setup-env.sh

Run mpirun wrapper command:

$ mpirun -np 4 -F openmpi -T intelmpi ./mpi_hello.exe

You are using Wi4MPI-%version in preload mode from OMPI to INTEL

Hello_world 0

Hello_world 2

Hello_world 3

Hello_world 1

Usage: mpirun [MPIRUN_TARGET_OPTIONS] -- [PROGRAM] [PROGRAM_OPTIONS]

Advanced options:

  -F | -from | --from {FROM}    MPI implementation PROGRAM was compiled with

  -T | -to   | --to   {TARGET}  MPI implementation to run PROGRAM with

The -F option is optional; if omitted, Interface mode is selected by default.

Example:

mpirun -np 4 -F openmpi -T intelmpi mpi_hello.exe

In this example, mpi_hello.exe is an OpenMPI binary executed under IntelMPI.

But, WI4MPI provides directly a dedicated launcher located at:

/path-install/wi4mpi-%version/bin/wi4mpi

Configure the paths to your MPI installations in:

/path-install/wi4mpi-%version/etc/wi4mpi.cfg

Run it with your TO mpirun launcher. For example:

/path/to/openmpi/mpirun wi4mpi -f openmpi -t intelmpi mpi_hello.exe

Or with Slurm launcher:

srun wi4mpi -f openmpi -t intelmpi mpi_hello.exe

WI4MPI is configurable 100% with environment variables:

• WI4MPI_ROOT: WI4MPI root installation path
• WI4MPI_CC: C compiler used by WI4MPI
• WI4MPI_FC: Fortran compiler used by WI4MPI
• WI4MPI_CXX: C++ compiler used by WI4MPI
• WI4MPI_RUN_MPI_C_LIB: Path to runtime MPI C library
• WI4MPI_RUN_MPI_F_LIB: Path to runtime MPI Fortran library
• WI4MPI_RUN_MPIIO_C_LIB: Path to runtime MPI-IO C library
• WI4MPI_RUN_MPIIO_F_LIB: Path to runtime MPI-IO Fortran library
• WI4MPI_WRAPPER_LIB: Path to interface wrapper library
• WI4MPI_APP_INCLUDES: Path to internal includes for JIT compilation
• WI4MPI_COMPILE_OPT: Compilation options for JIT compilation
• WI4MPI_INTERNAL_INCLUDE: Internal include path needed for JIT
• WI4MPI_FROM: MPI implementation used at compile-time
• WI4MPI_TO: Target MPI implementation at runtime
• LD_PRELOAD: Library preload mechanism (see man ld.so)
• LD_LIBRARY_PATH: Library search path (see man ld.so)

Preload settings

For a more step-by-step document, look at Translating MPI dynamically using Preload mode.

Set {FROM} and {TO} as OMPI or INTEL according to your conversion needs.

Example configuration:

# Example: OpenMPI → IntelMPI

export WI4MPI_RUN_MPI_C_LIB="/path/to/runtime/libmpi.so"

export WI4MPI_RUN_MPI_F_LIB="/path/to/runtime/libmpi_mpifh.so"

export WI4MPI_RUN_MPIIO_C_LIB="/path/to/runtime/libmpi.so"

export WI4MPI_RUN_MPIIO_F_LIB="/path/to/runtime/libmpi_mpifh.so"

export WI4MPI_APP_INCLUDES="path_to_wi4mpi/INTERNAL/preload/include/{FROM}_{TO}"

export LD_PRELOAD="path_to_wi4mpi/libexec/libwi4mpi_{FROM}_{TO}.so $WI4MPI_RUN_MPI_F_LIB $WI4MPI_RUN_MPI_C_LIB"

export LD_LIBRARY_PATH="path_to_wi4mpi/libexec/fakelibCXX:path_to_wi4mpi/libexec/fakelibOMPI:$LD_LIBRARY_PATH"

Interface settings

For a more step-by-step document, look at Translating MPI dynamically using Interface mode.

Set {FROM} and {TO} as OMPI or INTEL according to your conversion needs.

Example configuration:

# Example: Interface → IntelMPI

export WI4MPI_ROOT="/path_to_wi4mpi_install_root"

export WI4MPI_CC=icc

export WI4MPI_FC=ifort

export WI4MPI_CXX=icpc

export WI4MPI_RUN_MPI_C_LIB="/path/to/runtime/libmpi.so"

export WI4MPI_RUN_MPI_F_LIB="/path/to/runtime/libmpi_mpifh.so"

export WI4MPI_RUN_MPIIO_C_LIB="/path/to/runtime/libmpi.so"

export WI4MPI_RUN_MPIIO_F_LIB="/path/to/runtime/libmpi_mpifh.so"

export WI4MPI_WRAPPER_LIB="path_to_wi4mpi/lib_IMPI/libwi4mpi_CCC_{TO}.so"

export WI4MPI_APP_INCLUDES="path_to_wi4mpi/INTERNAL/interface/include/{FROM}_{TO}"

export WI4MPI_INTERNAL_INCLUDES="path_to_wi4mpi/INTERNAL/include"

export LD_LIBRARY_PATH="path_to_wi4mpi/lib:$LD_LIBRARY_PATH"
